Simulator SDK package

Requirements

  • naoqi-sdk of the same version than the simulator-sdk.
  • gcc > 4.4 or Visual Studio > 9 (2008)
  • cmake 2.8 (2.8.3 minimum on windows)

Introduction

The simulator-sdk is aimed at roboticists who want to simulate Aldebaran Robotics robots in their own 3D simulator.

It provides libraries, data, assets and examples.

Libraries

lib/ALRobotModel a C++ lib which describes all the Aldebaran-Robotics models (initial geometry, kinematics & dynamics data, sensors and actuators initial positions).
lib/ALNAOsim a C++ lib which enables to link the sensors / actuators to NAOqi (via the Hardware Abstraction Layer).
lib/ALSimUtils a C++ lib which launches automatically one naoqi per robot.

For further information, see: Simulator-SDK reference

Data and examples

share/alrobotmodel/meshes OGRE 3D format meshes.
share/alrobotmodel/meshes-src Blender format meshes.
share/alrobotmodel/models xml files defining robots. They should be provided to the ALRobotModel lib.
examples/dummysim a small example which shows how to use those lib.
examples/robot_description a tool which generates the description of all the Aldebaran-Robotics models in text or URDF format.

How it works

To use the simulator-sdk for your own simulator, you have to write a plugin that uses the libs of the simulator-sdk.

  • First, you have to instanciate a model by providing the xml file you want amongst those found under libalrobotmodel/models to the ALRobotModel lib.
  • Then, you should use your simulator API to get the physical values of the simulated world. These values should be transmitted into the sensors of the simulated robot. Use HALInterface::sendSensorValues functions for this.
  • Also, you should use the HALInterface to get the command values send by NAOqi to the actuators. Use HALInterface::fetchActuatorValues function for this. Finally use your simulator API to set these values to the actuators of the simulated robot.

The following figure summarizes this, and explains in further details how the simulator-sdk works.

../_images/simulator_sdk_functioning.png

How to build dummysim

Step Action

From the root of simulator-sdk, move to examples/dummysim/

cd examples/dummysim/

Create a build directory, and move into it

mkdir build && cd build

Configure the build with cmake

cmake -DCMAKE_TOOLCHAIN_FILE=../../../toolchain-pc.cmake ..

Compile

make

Execution of dummysim.

Do not forget to uncomment the dcm_hal in the file etc/naoqi/autoload.ini in the naoqi-sdk. Next, at the root of simulator-sdk:

on Linux:

bin/dummysim share/alrobotmodel/models/ROMEO.xml <naoqi_port> <naoqi_sdk>

on Mac:

DYLD_LIBRARY_PATH=lib bin/dummysim share/alrobotmodel/models/ROMEOH32.xml <naoqi_port> <naoqi_sdk>

on Windows:

launch bin/dummysim share/alrobotmodel/models/ROMEO.xml <naoqi_port> <naoqi_sdk>

Where:

<naoqi_port> is the port on which NAOqi will be launched and

<naoqi_sdk> is the sdk from which NAOqi will be launched.

Check that everything works fine:

  • Connect Choregraphe to 127.0.0.1:<naoqi_port>

    The Robot View shows a Romeo robot

  • Click on the green button: Stiffen all joints on/off in Choregraphe.

    If you move one joint, the robot shall move with a small delay. (the dummysim period is 1 sec!)

Various remarks

Multi-robot

You can instantiate several robots on the same computer by defining a port for each.

Units

Everything is in the Standard International.

Video

In its current implementation, the video does not work without NAOqi running.

How to generate URDF model and visualize it in rviz

Use robot_description to generate urdf:

Step Action
Install ros and rviz (see http://www.ros.org/wiki/)
Build robot_description (see How to build dummysim)

Use robot_description to generate the urdf file of the model you need. At the root of the simulator-sdk:

bin/robot_description --urdf --mesh-path=share/alrobotmodel/meshes --model-file=share/alrobotmodel/models/<model_name>.xml > <model_name>.urdf
Copy display_aldebaran.launch in the current directory

Visualize it with rviz (for more information, see http://www.ros.org/wiki/rviz):

rosrun urdf check_urdf <model_name>.urdf

roslaunch display_aldebaran.launch model:=<model_name>.urdf
